Features
Intelligent User Interface
PSX User Interface is agency-customizable, context-aware, and adaptive to the user’s changing tasks and environment. It improves productivity, situational awareness, and safety.
PSX Activity Builder allows agencies to create a custom User Interface that follows the agency’s workflow and operating procedures.
Suite of Sensors automatically detect ambient light, location, orientation, proximity, vibration, and drops to enhance context-awareness
APX P25 Radio Collaboration application provides BT-based remote control and management of radios' zones, channels, volume, signal strength, battery life, PTT and emergency. APX radio collaboration software required.
High Assurance Security
CRYPTR micro Hardware Encryption Module provides FIPS 140-2 Level 3 compliant security for voice and data in transit.
Security Enhanced (SE) Android provides secure boot and application white-listing, protecting the device and its data at rest from cyber threats.
Security Management Services include Mobile VPN, certificate management, key management, device management, and identity management in order to prevent unauthorized access and information leaks.
Reliable Connectivity
Commercial LTE Network (Band 13 and 4) network access with 3G auto-fallback.
Public Safety LTE (Band 14) network access with optimized algorithms for better performance while switching across networks; FirstNet-ready.
Dual SIM Slots for dual network access providing optimal coverage and performance.
Bluetooth 4.0 and WiFi 802.11n with Miracast enables flexible, standards-based connectivity to peripheral devices and accessories.
Mission Critical Bluetooth enables fast, secure, near-field touch pairing with compatible Motorola devices and accessories.
Purpose-built Ergonomics
4.7” Capacitative Touch screen is outdoor readable in sunlight.
Dedicated and textured PTT button provides tactile feedback for fast voice collaboration.
Covert Mode enables discreet, low-profile operation during surveillance missions at night.
No-slip Grip Texture enables one-handed operation even with wet-hands or gloves.
Removable 20-hour Battery enables the use of spares, making it easy to continue operation in the field without having to wait for recharge.
Best-in-class Audio
Dual 1-watt front-facing speakers deliver best-in-class clarity and loudness at 106 dB of Sound Pressure Level (SPL).
Triple microphones provide best-in-class voice clarity, noise reduction and echo cancellation.
Relentless Durability
IP67 rating to withstand dust, rain and water immersion of 1 meter for 30 minutes.
MIL-STD 810 G rated to withstand 4 ft drops to concrete.
Rubberized Top and Bottom surfaces help the device absorb impact.
Gorilla Glass 3 is resistant to scratches, drops and pressure.
Specification Sheet
LEX L10 Data Sheet
LEX L10 Specifications Sheet
Performance Characteristics
-
Memory
2 GB RAM
16 GB eMMC
Expandable to 64 GB with microSD™ card
-
Processor (CPU)
Qualcomm MSM8974AB - 2.3 GHz Quad Core Processor
-
Operating system (OS)
Android™ KitKat 4.4.4 Operating System
-
Battery
Standard - 2280 mAh, 10 hours
High Capacity - 4560 mAh, 20 hours
-
Audio
Supported formats:
MP3, WAVE, AAC, AMR-NB, AMR-WB, FLAC, MIDI, Vorbis
Outputs:
Dual 1 Watt Front-Facing Speakers, 106 dB Sound Pressure Level (SPL)
3.5 mm audio jack (stereo)
Bluetooth (A2DP stereo)
-
Video
Supported formats:
H.263, H.264, MPEG-4 SP, VP8, JPEG (.jpg), GIF (.gif), PNG (.png), BMP (.bmp), WebP (.webp) Formats supported for playback, streaming and recording
Supported file types:
3GPP (.3gp), MPEG-4 (.mp4), WebM (.webm), (.mkv)
Video Recording Quality:
1080p HD up to 30 frames per second (fps)
Video and images are time stamped for evidence documentation
-
Device software
User Interface: Public Safety Experience
Messaging:
SMS/MMS Email (Corporate Sync, POP3, IMAP, Push Email)
Web:
Standard AOSP Browser
-
Device management
Supports OMA-DM Open Mobile Alliance Device configuration
Physical Characteristics
-
Dimensions (HxWxD)
5.62 x 2.85 x 0.547 in
(143 x 72.6 x 13.9 mm) -
Weight
195 grams including standard battery
-
Display
4.7 in, 720X1280 capacitive, touch screen
-
Camera
Front 2MP camera,
rear 8MP camera, auto focus, single LED flash, digital zoom
-
Ports
USB 2.0 high-speed (micro-A interface),
3.5 mm audio jack (stereo),
accessory/charging port
User Environment
-
Operating temperature
14°F to 131°F (-10°C to +55°C)
-
Storage temperature
-22°F to 140°F (-30°C to +60°C)
-
Drop specification
Continues to run after multiple drops to concrete from a height of 48 inches (121 cm);
Drop tested using MIL-STD-810G Method 516.6, Procedure IV
Wireless Data Communications
-
WLAN
802.11 a/b/g/n
2.4 GHz, 5 GHz
Hotspot & Miracast
-
Bluetooth
Bluetooth 4.0 Low Energy (LE) + Enhanced Data Rate (EDR)
Mission Critical Wireless Bluetooth
Max throughput 2.1 Mbps
A2DP Stereo Profile
-
LTE
Release:
3GPP Release 9
Bands:
3, 13
Band 14 (Public Safety LTE)
Output Power:
23 dBm +/- 2 dB (UE power class 3)
Bandwidth:
Up to 20 MHz Broadband data throughput depends on network conditions
-
GPS
Location services:
Standalone GPS Assisted GPS (aGPS) E-Compass
